SICK CSS-WBGAD4118AA10Z, High-resolution color sensor
Manufacturer: SICK.
Model: CSS-WBGAD4118AA10Z.
Type: High-resolution color sensor.
Sensing Distance: 50 mm to 500 mm.
Light Source: RGB LED.
Power Supply: 10.8 V to 28.8 V DC.
Connection: M12, 8-pin male connector.
Enclosure Rating: IP67.
Features: It can distinguish between fine color nuances and structured materials, and can output color values in RGB or Lab formats. It also has an IO-Link interface and can save up to 24 colors per task.
Sick DME3000-311S17 Laser Distance Sensor, an industrial automation component
Sick DME3000-311S17 Laser Distance Sensor, an industrial automation component used for high-precision, non-contact measurement.
Technical Specifications
Based on the label and matching product data:
Model Number: DME3000-311S17.
Part Number: 1 023 508.
Power Supply: DC 18...30V.
Country of Origin: Made in Germany.
SICK KT5W-2B1116 Contrast Sensor (Part No. 1043006)
SICK KT5W-2B1116 Contrast Sensor (Part No. 1043006). It is an industrial sensor used for high-precision detection of print marks and color combinations, even on high-gloss or reflective materials.
Key Specifications
Sensing Distance: 10 mm.
Light Source: 3-color RGB LED (Red, Green, Blue) that automatically selects the optimal light for the best contrast.
Supply Voltage: 10 to 30 V DC.
Output Type: Dual switching output with both PNP and NPN.
Switching Frequency: 10 kHz, allowing for very fast machine processes.
Protection Rating: IP67, making it dust-tight and resistant to water immersion.
Housing Material: Rugged zinc diecast metal housing.
Sunx NX-5 series photoelectric beam sensor
Sunx NX-5 series photoelectric beam sensor. Specifically, it matches the form factor and wiring diagram for multi-voltage sensors in this series, such as the NX-51 or NX-52 models.
Technical Specifications
According to the label on the device:
Supply Voltage: 24 to 240V AC/DC (±10%).
Output Type: Relay contact output with NO (Normally Open), COM (Common), and NC (Normally Closed) terminals.
Manufacturer: Sunx (now part of Panasonic Industry).
