Beckhoff KL2541 Stepper Motor Terminal
DM860H 2H Microstep Driver, a motor controller module used to control stepper motors
DM860H 2H Microstep Driver, a motor controller module used to control stepper motors.
Essential information:
Model: DM860H 2H Microstep Driver
Purpose: It is used to control two-phase stepping motors.
Specifications: It can handle a supply voltage from 18V to 80V AC or 24V to 110V DC and has a peak current of up to 7.2A.
Leadshine 57CME23 Easy Servo Motor, a 2-phase NEMA 23 closed-loop stepper motor
Leadshine 57CME23 Easy Servo Motor, a 2-phase NEMA 23 closed-loop stepper motor integrated with a 1,000-line incremental encoder. Key Specifications Frame Size: NEMA 23 (57 mm)Holding Torque: \(2.3\text{\ N}\cdot \text{m}\) (approximately 326 oz-in)Phase Current: 5.0 AStep Angle: \(1.8^{\circ }\)Shaft Diameter: 8 mmMax Speed: Approximately 2,000 RPMWeight: 1.17 kg Wiring Information The label on the motor provides the specific wiring configuration for both the motor phases and the encoder: Connection Type TerminalWire ColorMotor WiringA+Black
